F65-1J单组铰链钻孔机single group hinge boring machine

F65-2J双组铰链钻孔机double-group hinge boring machine

F65-3J三组铰链钻孔机three-group hinge boring machine

F65-4J四组铰链钻孔机four-group hinge boring machine

*进口原装铰链头，名优电器原件。

*机床部位选用优质钢材，经高强度热处理，永不变形。

*运动部件，选用高级耐磨材料，经久耐用。

*尺寸定位，操作方便，快速准确。

*lmported superior drill rows and electronic appliance.

*The machine base is made of superior steel material.heat-treated under high intensity,Non-derorm ation.

*The moving parta adopt quality anti-wear materials,durable in use.

*Gauge positioning,easy operation,proeration,prompt and accurate working.

技术参数The Technical Paramerter

电源

Power Source：

380V/50Hz

气源

Gas source:

≥0.6kg/c㎡

铰链孔距

Boring distance:

920(最大Max)—180mm(最小/Min)

电机总功率

Total power:

2.2KW

机器尺寸

Machine size:

1600×820×1200mm

机械重率

Machine weight:

400kg
